Siemens SIMATIC S7-1500 DQ 16 × 24 V DC/0.5 A HF Digital Output Module – 6ES7522-1BH01-0AB0
The Siemens 6ES7522-1BH01-0AB0 is a SIMATIC S7-1500 digital output module providing 16 channels rated at 24 V DC, 0.5 A per channel. It combines single-channel diagnostics, substitute-value functionality, and a switching-cycle counter for connected actuators. Outputs are arranged in two groups of eight, with 4 A per group.
PRODUCT SPECIFICATIONS
· Brand: Siemens
· Product Family: SIMATIC S7-1500
· Order Number: 6ES7522-1BH01-0AB0
· Module Type: Digital Output Module
· Module Designation: DQ 16 × 24 V DC/0.5 A HF
· Digital Output Channels: 16
· Output Voltage: 24 V DC
· Output Current: 0.5 A per channel
· Channel Grouping: 8 channels per group
· Number of Output Groups: 2
· Current per Group: 4 A
· Diagnostics: Single-channel diagnostics
· Additional Functions: Substitute value and actuator switching-cycle counter
· Front Connector: Ordered separately
· Connector Options: Screw terminals or push-in
BENEFITS
· Helps narrow troubleshooting to individual output channels.
· Makes actuator switching counts available for maintenance planning.
· Adds 16 output connections for suitable machine devices and control circuits.
· Offers a choice of screw-terminal or push-in front connectors to suit the wiring approach.
APPLICATION
· Interface Relays: Switch suitable relay coils with appropriate protection.
· Solenoid Valves: Operate compatible valve coils within the electrical ratings.
· Status Indicators: Control suitable 24 V DC lamps according to programmed machine states.
· Actuator Monitoring: Use switching counts as one input to maintenance decisions.
· Front Connector Selection: Order the required screw-terminal or push-in connector separately.
